Industrial Sewage Treatment Plant
Engineered for High-Load Industrial Effluent | Robust | Efficient | Reuse-Ready
VEPL’s Industrial Sewage Treatment Plant is designed to handle high-strength wastewater generated by manufacturing, processing, and commercial units. Built with advanced biological and physico-chemical treatment technologies, our STPs ensure consistent performance even under variable hydraulic and organic loads.
Whether it’s textile, food processing, pharmaceutical, chemical, or automotive industries — VEPL offers scalable and customized STP systems that meet CPCB norms and enable treated water reuse for non-potable applications.
Product Overview
VEPL Industrial STPs are designed with robust components, engineered to treat a wide range of contaminants including BOD, COD, TSS, oil & grease, ammonia, and heavy metals. We integrate proven technologies like MBBR, SBR, ASP, and Tertiary Treatment + UF/RO for achieving superior output quality.
Technical Specifications
Parameter | Specification |
Treatment Capacity | 10 KLD to 5 MLD (customized to application) |
Technology Used | MBBR / SBR / ASP / Hybrid |
Material of Construction | RCC / FRP / MSEP / HDPE (as per client need) |
Aeration System | Fine bubble diffused system |
Media Type | Biofilm carrier media (for MBBR) |
Automation | Manual / Semi-auto / Fully Automatic (PLC/SCADA) |
Filtration Unit | PSF, ACF, Micron Filters, UF/RO (as required) |
Power Requirement | 5 – 50 HP (based on capacity) |
Sludge Handling | Sludge Dewatering Unit / Filter Press / Drying Beds |
Compliance | Meets CPCB / SPCB / MoEF guidelines |
Inlet & Outlet Water Quality Parameters
Primary Treatment (Screening + Oil & Grease + Equalization)
Parameter | Inlet Range | Outlet Range |
pH | 5.5 – 9.0 | 6.5 – 8.5 |
BOD | 300 – 800 mg/L | 150 – 200 mg/L |
COD | 600 – 1500 mg/L | 300 – 600 mg/L |
TSS | 250 – 600 mg/L | 100 – 200 mg/L |
Oil & Grease | 20 – 100 mg/L | < 20 mg/L |
Heavy Metals | Trace to Moderate | Reduced (if present) |
Secondary Treatment (Biological Reactor + Clarification)
Parameter | Inlet | Outlet |
BOD | 150 – 200 mg/L | < 30 mg/L |
COD | 300 – 600 mg/L | < 100 mg/L |
TSS | 100 – 200 mg/L | < 30 mg/L |
Ammonia (NH4) | 20 – 50 mg/L | < 10 mg/L |
Sulphates/Nitrates | Present | Reduced |
Tertiary Treatment (Pressure Sand Filter + ACF + Disinfection)
Parameter | Inlet | Outlet |
BOD | < 30 mg/L | < 10 mg/L |
COD | < 100 mg/L | < 30 mg/L |
TSS | < 30 mg/L | < 5 mg/L |
Pathogens | Present | 99% Removed |
Odor / Color | Mild | Removed |
Ultrafiltration (UF – Optional Final Polishing)
Parameter | Inlet | Outlet |
BOD | < 10 mg/L | < 5 mg/L |
TSS | < 5 mg/L | < 1 mg/L |
Turbidity | < 5 NTU | < 1 NTU |
Pathogen Removal | Partial | 99.99% |
Water Reuse | Cooling, Flushing, Process Use | ✅ |
Applications
- Food & Beverage Industries
- Pharmaceuticals & Hospitals
- Chemical & Petrochemical Plants
- Textile & Dyeing Units
- Automobile & Engineering Units
- Packaging, Printing, & Paper Industry
- Industrial Estates and SEZs
Key Features
- Heavy-Duty Construction – Built for industrial environments
- High Shock Load Handling – Ideal for variable loads
- Water Reuse-Ready – Suitable for cooling towers, toilets, floor washing
- Custom-Built Designs – Technology & capacity tailored to your need
- Smart Automation – Optional PLC/SCADA-based operation
- Sludge Management – Integrated dewatering solutions
