VEPL Prefabricated Sewage Treatment Plant (MBBR-Based)
Technology: Moving Bed Biofilm Reactor (MBBR) Design Type: Prefabricated, Modular, Above-ground/Containerized
Ventilair Engineers Pvt. Ltd. (VEPL) proudly offers a natural, sustainable, and zero-energy sewage treatment solution — the Eco-Friendly Reed Bed Sewage Treatment System, also known as Plantation-Based STP. This system treats domestic sewage through constructed wetlands and rooted plants, mimicking nature’s own purification process.
Ideal for eco-resorts, farmhouses, rural institutions, hostels, schools, and off-grid housing, this solution offers low-cost operation, zero energy consumption, and near-zero maintenance, while complying with CPCB / State Pollution Control Board norms.
Technical Specifications:
Specification | Details |
Capacity Range | 10 KLD to 500 KLD (customized) |
Technology | MBBR (Moving Bed Biofilm Reactor) |
Design Format | Prefabricated / Containerized (MS+FRP, HDPE, or SS304) |
Power Supply | 415V AC, 3 Phase, 50 Hz |
Operation | Semi-Automatic / PLC-based Fully Automatic (Optional) |
Installation | Above-ground / Portable / Capsule-Type |
Footprint | Compact (modular design with stackable options) |
Components & Accessories Included:
- Bar Screen Chamber – Manual or mechanical coarse/fine screening
- Oil & Grease Trap – Removes floating oil, especially for kitchen/canteen wastewater
- Equalization Tank – Maintains consistent flow, equipped with air mixing
- MBBR Bioreactor – Aeration tank with bio media and diffusers
- Air Blowers – Twin lobe/centrifugal oil-free blowers
- Bio Media – Floating type (specific surface area > 500 m²/m³)
- Tube Settler / Secondary Clarifier – Solids-liquid separation
- Sludge Holding Tank – With submersible dewatering pump
- Tertiary Treatment Unit:
- Pressure Sand Filter (PSF)
- Activated Carbon Filter (ACF)
- Ultrafiltration (UF) System – Hollow fiber membranes (0.01–0.1 micron)
- Disinfection Unit – UV/Chlorine dosing (as required)
- Control Panel – IP65 PLC-based with sensors & indicators
- Level Controllers, Flow Meters, Valves, Piping
- Ventilation, Ladder, Platform & Safety Accessories (as applicable)
Treatment Process Flow Description:
Primary Treatment:
- Screening Unit removes floating and large solids.
- Oil & Grease Trap eliminates fats and oils.
- Equalization Tank with air mixing handles flow/load variations.
Secondary Treatment (MBBR Process):
- Wastewater enters the MBBR aeration tank filled with floating bio-media.
- Aerobic microorganisms form biofilm on the media and degrade organic pollutants (BOD/COD).
- Blowers supply oxygen through fine bubble diffusers.
Secondary Clarification:
- Water flows into Tube Settler or Clarifier for separation of biological sludge.
- Sludge is collected in a holding tank for periodic disposal.
Tertiary Treatment:
- Treated water passes through Pressure Sand Filter (PSF) and Activated Carbon Filter (ACF) to remove fine particles, color, odor, and residual organics.
- Followed by chlorine dosing or UV disinfection for pathogen removal.
Ultrafiltration (UF) – Advanced Polishing Stage:
- UF membranes (0.01 micron) remove bacteria, viruses, turbidity, suspended solids, and any residual organic matter.
- Final effluent is suitable for reuse in flushing, gardening, car washing, or discharge as per CPCB norms.
Inlet and Outlet Parameters:
Parameter | Inlet (Raw Sewage) | After Tertiary Treatment | After UF (Final Outlet) |
pH | 6.5 – 8.5 | 6.8 – 8.5 | 6.8 – 8.5 |
BOD (mg/L) | 250 – 400 | < 10 | < 5 |
COD (mg/L) | 500 – 700 | < 30 | < 10 |
TSS (mg/L) | 250 – 350 | < 10 | < 5 |
Oil & Grease (mg/L) | 20 – 30 | < 5 | < 1 |
Turbidity (NTU) | 150 – 200 | < 5 | < 1 |
Pathogens | Present | Reduced | Nil (Log 4–6 removal) |
Color & Odor | Objectionable | Removed | Colorless, odorless |
Complies with CPCB & State Pollution Control Board discharge norms
Final treated water is safe for reuse in flushing, landscaping, cooling towers, etc.
Key Advantages of VEPL MBBR Capsule STP:
- Compact Footprint – Prefabricated capsule-type design
- Fast Installation & Commissioning
- Robust Biological Treatment (MBBR)
- Modular Scalability
- Low Operation Cost
- Zero Odor and Noise
- Reusability of Treated Water
Smart Automation Options Available
